Clean water and sewage diversion series

1. Product Overview​

The Insertable Flexible Flow Control Device primarily consists of a sealed rubber capsule. The system mainly comprises an insertable flexible capsule, a control cabinet (including the pneumatic system and accessories), a level sensor, and other components. Designed as an in-pipe structure, it operates by using controlled compressed air to inflate and deflate the internal air bladder of the rubber capsule, thereby completing the closing and opening actions of the device. The level sensor detects the water level on both sides of the pipe and converts it into electrical signals for the control system. When flow control is required, the air compressor fills the air bladder with compressed gas, deforming the rubber to close the passage. For flood discharge, the deflation ball valve is opened, allowing the rubber tube to restore its shape. Under the pressure of the water head, the rubber rapidly returns to its original form.

2. Advantages of the Insertable Flexible Flow Control Device​

• No Pipeline Modification Required:​ Features a unique insertable design that allows installation and operation without altering the original pipeline.
• Clog-Free Operation:​ Highly resistant to tangling and clogging. Debris such as entangled materials or floating objects in the pipeline will not block the device. Once installed, the flow path aligns completely with the pipeline, resulting in zero head loss.
• Compact Vertical Profile:​ The device occupies minimal vertical space during installation and does not protrude above ground. Its fully flexible seal provides a large sealing surface, ensuring zero leakage.
• Simple and Robust Structure:​ Designed to operate reliably even in sewage environments for extended periods without failure.
• Unaffected by External Factors:​ The flexible diversion well continues to function normally even during waterlogging in residential areas.
• Easy Maintenance:​ Simple and convenient installation, maintenance, and servicing, with a long service life.
